Model DEB LED Lamp
Recommended Product
KJT
KJT
For more details on Model DEB
Refer to the “Replacement Bulb”
Section at the end of this Catalog
Melody/Alarm & LED Tower
Bulb
8 Channels
95dB at 1m
IP23
116
(Bit)
NPN
Open-collector
Multi-tiered Revolving Warning Light integrated
with voice synthesizer or melody alarm for various
applications.
•
•
•
•
•
•
FEATURES
Eight Channels for Bit Input. (Binary Input: 32)
Lens is made of superior weather-resistant and light-translucent acrylic resin.
Built-in adjustable sound of up to 95dB (at 1m) with volume control.
Warning lights and alarms can be controlled together or separately.
Available Colors are in Red, Amber, Green, and Blue.
Installation is available in the upright position only.
Sound Chart
How to Order
Type E
Beep (slow intermittent)
Stutter + Bell
Inverted Reveille
Stutter (rapid intermittent)
Melody Chime
Galactic Motor
London Bridge is falling down
Bell (clear high-pitch)
Chime
Ringing Phone
Mary had a little Lamb
Yelp (rapid siren)
Call Sign
Two Tone
Camptown Races
Rapid Hi-Lo
Train Ride
Alarm Clock
Amaryllis
Melody Chime
Galloping Hi-Lo
Ringing Hi-Lo
Mozart Symphony No. 40
Synthesized Piano
Alien Chatter
Fur Elise
Ave Maria
Synthesized Bell
Falling Crystals
Bach Minuet in Gmaj
Grandfather’s Clock
Use of Copyrighted Material
PATLITE Corporation has not applied for permission to use certain copyrighted music or
songs recorded for Type-A, Type-C and Type-D melody charts outside of Japan. Therefore,
please contact the local copyright association for permission before using the product
in case this product is used outside of Japan. melody chart Type-E is recommended for
use outside of Japan as this playlist does not include copyrighted music or songs, and
permission is not required.
192
KJT-302A-RYG
Annie Laurie
Model
Tiers
1-3
Rated Voltage
02: DC 24V
10: AC 100V
20: AC 200V
Sound Type
A: Type A
C: Type C
D: Type D
E: Type E
Color
R: Red
Y: Amber
G: Green
B: Blue
(Top to bottom)
