Dimensions

KJT

116
Height (mm)
1 Tier: 232
2 Tiers: 337
3 Tiers: 442

Mounting Dimensions

4
Standard
Mounting Bracket
SZ-008

74

12

Height

74

32

12

Mounting Hole
4- ø7

Wire Exit Hole ø11
17

(Unit: mm)

Wiring

External
Contact

Red LED Unit (Red)
Yellow LED Unit (Yellow)
Green LED Unit (Green)
Audio CH1 (Sky Blue)
Audio CH2 (Yellow)
Audio CH3 (Pink)
Audio CH4 (Bright Green)
Audio CH5 (Red)
Audio CH6 (Orange)
Audio CH7 (Green)
Audio CH8 (Blue)

3
2
1

Common Line (Brown)
Power Supply + (White)
Power Supply - (Black)
Fuse 5A

Power
Supply

Channel Priority:
8 (Blue) > 7 (Green) > 6 (Orange) > 5 (Red) > 4 (Light Green) > 3 (Pink) > 2 (Yellow) > 1 (Skyblue)
The greater number has priority when any of the channels are activated simultaneously.

Specifications
Model

1 Tier

Alarm/
2 Tier
Melody

3 Tier

Rated Voltage
KJTKJTKJTKJTKJTKJTKJTKJTKJT-

102
110
120
202
210
220
302
310
320

24V AC/DC
AC 100V
AC 200V
24V AC/DC
AC 100V
AC 200V
24V AC/DC
AC 100V
AC 200V

Operating
Voltage Range

Power
Bulb
Rotations
Sound Level
Consumption Ratings Repl. No. per Minute
AC/DC 21 - 27V
25W/18W 24V 10W
10
135
AC 90 - 110V
20W
12V 5W
12
120
AC 180 - 240V
AC/DC 21 - 27V
36W/28W 24V 10W
10
135
95dB (at 1m)
AC 90 - 110V
26W
12V 5W
12
120
AC 180 - 240V
AC/DC 21 - 27V
47W/38W 24V 10W
10
135
AC 90 - 110V
32W
12V 5W
12
120
AC 180 - 240V

Operating
Temperature Range

Channels

Mass
1.4kg
1.7kg

o

2.0kg

o

-20 C - +50 C
(85%RH or less)

8 Ch

2.4kg
2.6kg
3.0kg
