RT
RT
MP3
Hybrid MP3 & Revolving Light
Bulb
32 Alarm Sounds
105dB at 1m
63 Seconds
IP23
NPN
Open-collector
Large horn with revolving warning light featuring clear
sound up to 105dB (at 1m).
•
•
•
•
•
•
•
•
•
•
FEATURES
Built-in Adjustable alarm with a sound of up to 105dB (at 1m).
High sound quality with the MP3 voice synthesizer (RT-VF only).
Installation is in the upright position only.
Dome is made of superior weather-resistant and light-translucent acrylic resin.
Available colors are Red, Amber, Green, and Blue.
Complies with EU directives and includes the CE mark (for 24V type).
AVAILABLE BY SPECIAL ORDER
Cable: Versatile and flexible 3m cable
AC 120V type
IP65 rating
UL Conformity
Horn Configuration Concept
105dB (at 1m)
Standard
Mounting Bracket
SZ-008
Dimensions
How to Order
162
RT-24VF-R
260
50
Wire Exit Hole:
ø15
ø140
200
190
Mounting Hole:
3- ø9
12
0°
Sound
VF: Voice Synthesizer
A: Type A
C: Type C
D: Type D
E: Type E
Front
128
Rated Voltage
24 : DC 24V
100: AC 100V
200: AC 200V
Mounting Dimensions
Color
R: Red
Y: Amber
G: Green
B: Blue
198
88
120°
(Unit: mm)
