BDV
BDV
MP3
Voice Annunciator
BDV-15JF Only
87dB at 1m
15 Channels
63 Seconds
IP54
80
(Binary)
(Upright Only)
NPN
Open-collector
Excellent sound quality with MP3 playback! This panelmounted MP3 voice annunciator uses SD cards*, allowing
messages to be changed easily. (*Recommended: SDV-2GP)
FEATURES
Only Flush-mounting style available.
Able to produce a loud sound of up to 87 dB (at 1m) despite its compact size
A volume control on the front panel provides an easy way to adjust the sound volume.
The use of an SD card allows message changes without uninstalling the device.
Environmentally friendly since the unit complies with the EU RoHS Directives.
Several playback modes are available for various applications.
Includes binary input as a standard option for selecting up to 15 messages.
Supports input selection using NPN open-collector transistor.
The unit complies with EU Directives and includes the CE mark (BDV-15JF only)
Two colors are available for selecting the best color match for the installation.
Protection rating: IP54 (only the front panel when flush-mounted)
How to Order
Dimensions
80
BDV-15JF-J
Rated Voltage
17.2
Color
J: DC 12-24V
K: AC 100V/220V
79.5
15.2
J: Ivory White
K: Dark Gray
67.5
•
•
•
•
•
•
•
•
•
•
•
15.5
Mounting Hardware
176
Movable Front Cover Range
(Unit: mm)
