Dimensions
How to Order
19.9
BSV-24NM-W
7
Front Cover Color
W: Off-white
D: Dark Gray
S: Silver
Pre-recorded Message
None: 15 Built-in Alarms
M : Pre-recorded Messages
(Caution) If the pre-recorded voice message data is
overwritten, all of it will be erased.
Also, message data cannot be exported.
500
5mm Stripped
Transistor Type
N: NPN
P: PNP
BSV
□75
Mounting Dimensional Drawing
+0.7
□68-0 mm
□57.5±0.2
Wall Mount
Mounting Dimensions
(Product Front View)
Panel Mount
Mounting Dimensions
※ Thickness (1mm∼3.5mm)
Panel Mount
2-φ3.5
(Unit: mm)
※ Dimensions are IEC-61554 (DIN-43700) compliant
Wiring
Wall Mount
※
※
CH4 Light Green
CH4 Light Green
CH3 Peach
Non-voltage
Contact Circuit
CH3 Peach
Voltage
Contact Circuit
CH2 Yellow
CH2 Yellow
Actual Size
CH1 Sky Blue
CH1 Sky Blue
Power (-) Black
Power (-) Black
Fuse
Power (+) White
CH4
NPN
Transistor
Circuit
Power (+) White
※
Fuse
※
PNP
Transistor
Circuit
CH3
CH4
CH3
CH2
CH2
CH1
CH1
Power (-)
Power (-)
Fuse
Power (+)
Power (+)
Fuse
With the built-in SD card slot, MP3 data rewriting
can be done with an SD card.
In addition to the optional message rewriting with
the exclusive PATLITE Playlist Editor 2 Application
software, Rewriting or editing MP3 data files is
possible without the use of dedicated software.
Specifications
Transistor Pre-recorded
Type
Data
VOICE
NPN
ALARM
VOICE
PNP
ALARM
Model
BSVBSVBSVBSVBSVBSVBSVBSVBSVBSVBSVBSV-
24NM24NM24NM24N24N24N24PM24PM24PM24P24P24P-
W
D
S
W
D
S
W
D
S
W
D
S
Front
Operating
Sound
Operating
Maximum No. of
Rated
Power
Protection
Cover
Voltage
Level Temperature Playback Playback
Mass
Voltage
Consumption
Rating
Color
Range
(Max.)
Range
Time
Inputs
Off-white
Dark Gray
Silver
Off-white
Dark Gray
IP54
Silver
Bit: 4
12-24V
10.8V 87dB
-10 - +50oC
63 sec.
(Flush-mount, 100g
3.5W
Binary: 15
DC
26.4V DC
(at 1m) (RH less than 85%)
Off-white
Upright Position)
Dark Gray
Silver
Off-white
Dark Gray
Silver
*Actual sound level will depend on sound type and surrounding operating conditions.
175
