Wiring Diagram
Wiring when using
NPN Transistor
CH4
Fuse
250V 0.5A
CH4
Not Used
CH3
CH3
CH2
Fuse
125V 0.5A
CH1
Fuse
125V 0.5A
CH2
BDV
Wiring when using
NPN Transistor
AC 220V
DC 12-24V
COM
AC 100V
CH1
COM
Playback Modes
Up to 87dB (at 1m)
Despite its slim appearance, it is able to produce a maximum of 87dB (at 1m).
(Actual sound level will depend on sound type and surrounding operating conditions.)
Mode Selector Switch
Several playback modes for a combination of applications.
A Bit Input Mode
B
Binary Input
Mode
Plays back up to 4 messages using Channels
1 to 4.
Plays back up to 15 messages using
Channels 1 to 4.
Plays back up to 3 messages using Channels
Bit Input/
1 to 3. When Channel 4 receives an input,
C Volume
Reduction Mode the volume is re
