Super-bright LED Revolving Warning Light
RKEM
RHEM/RKEM
RKEM/ RHEM
LED
IP55 (with SZ-200A)
Φ100
Brushless Motor
RHEM
Compact LED revolving warning light featuring one superbright LED chip with an enhanced dispersion reflection system
and brushless motor.
FEATURES
Has the CE mark and conforms to the requirements (for 12V, 24V type only) for the EC directive.
Brushless compact motor with high durability and long-lasting characteristics.
Dome lens is made of impact and heat resistant polycarbonate resin.
Energy-efficient by using only 1 LED chip which is super-bright.
Main body is made of impact and heat resistant ABS resin.
Colors available are Red, Amber, Green, and Blue.
Uses a terminal block for easy wiring.
Dimensions
RKEM -
-
Model
RKEM
RHEM
Rated Voltage
12 : DC 12V
24 : DC 24V
M2 : AC 100 - 200V
Color
R: Red
Y: Amber
G: Green
B: Blue
Specifications
Nameplate
120°
12°
148
92
Model
φ70
RKEM-12
RKEM-24
RKEM-M2
RHEM-12
RHEM-24
RHEM-M2
Mounting Hole
3-ø6
70°
Wire Exit Hole
25°
R14
R45
Wire Exit Hole
120°
16
3-M5
How to Order
Mounting Dimensions
ø100
49
•
•
•
•
•
•
•
(Unit: mm)
Conventional Motor Construction
Power
supply
Magnet
Shaft
Brush
Rated
Current
Flash Mass
Voltage
Consumption
Rate
DC 12V
0.20A
DC 24V
0.14A
AC 100-200V 0.20A-0.06A
120 fpm 400g
DC 12V
0.20A
DC 24V
0.14A
AC 100-200V 0.20A-0.06A
Brushless Motor Construction
Power
supply
Coil
Electric circuit
Shaft
Magnet
Coil
Commutator
Brush
Magnet
Coil
