30RQY 017-033
Physical data
30RQY
Air conditioning application as per EN14511-3 : 2013
Condition 1/condition 2
kW
Nominal cooling capacity
EER
kW/kW
Eurovent class, cooling (condition 1)
ESEER (condition 1)
kW/kW
Heating application as per EN14511-3:2013
Condition 1/condition 2
kW
Nominal heating capacity
COP
kW/kW
Eurovent class, heating (condition 1)
Operating weight*
Standard unit (with hydronic module)
kg
Standard unit (without hydronic module)
kg
Refrigerant*
Compressor
Control
Fans
Air flow
l/s
Evaporator
Condenser
Unit with hydronic module
Dimensions
Length x depth x height
mm
017
021
026
033
14.9/18.4
2.51/2.82
B
2.78
19.0/23.9
2.53/2.91
B
2.74
27.1/35.6
2.70/3.42
A
3.03
32.3/41.3
2.95/3.50
A
3.2
17.0/17.5
2.66/3.21
C
20.5/20.8
2.67/3.16
C
28.8/29.9
2.59/3.22
D
31.4/32.3
2.67/3.21
C
226
243
280
295
211
228
262
277
R-410A
One scroll compressor
Pro-Dialog+
Two twin-speed centrifugal fans, 5 backward-curved blades
One twin-speed axial fan, 7 blades
1640
1640
3472
3472
One plate heat exchanger
Copper tubes and aluminium fins
One single-speed pump, screen filter, expansion tank, flow switch, water circuit drain valve, pressure gauge, automatic air purge valve, safety valve
1135 x 584 x 1608
1135 x 584 x 1608
1002 x 824 x 1829
1002 x 824 x 1829
NOTE: For the conditions please refer to page 73.
*
Weight shown is a guideline only. To find out the unit refrigerant charge, please refer to the unit nameplate.
Electrical data
30RQY
017
021
026
033
Power circuit
Nominal power supply
V-ph-Hz
400-3-50 ± 10%
24 V via internal transformer
Control circuit supply
A
75
95
118
118
Maximum start-up current (Un)*
kW
8.0
9.3
11.2
14.0
Maximum operating power input**
A
13
16
20
24
Nominal unit operating current draw***
*
Maximum instantaneous start-up current (locked rotor current of the compressor).
**
Power input, compressors and fans, at the unit operating limits (saturated suction temperature 10°C, saturated condensing temperature 65°C) and nominal voltage of 400 V (data given on the unit nameplate).
*** Standardised Eurovent conditions: water heat exchanger entering/leaving water temperature 12°C/7°C, outside air temperature 35°C.
Operating range
Cooling mode
Heating mode
53
40
48
38
Outside air temperature, °C
Outside air temperature, °C
43
33
28
23
18
13
8
3
20
10
0
-10
-2
-7
-12
30
-20
