DUCTABLE Air-to-water
heat pumps
Heating
Reversible
Options/accessories
• Hydronic module (option)
• Integrated water fill system (option/
accessory)
• Inlet duct frame (option)
• Inlet filter frame (option)
• JBus, BacNet and LonTalk gateways
(accessory)
• Remote interface (accessory)
• Condensate drain pan (accessory)
30RQY
Features
• Four sizes with nominal cooling capacities from 15 to 32 kW and nominal
heating capacities from 17 to 31 kW.
• Aquasnap heat pumps for commercial applications such as the air conditioning
of offices and hotels.
• Exceptionally high energy efficiency at part load - Eurovent energy efficiency
class A and B in cooling mode and C in heating mode
(in accordance with EN14511-3:2013).
• Integrates the latest technologi al innovations: ozone-friendly refrigerant R-410A,
c
scroll compressors, low-noise fans and auto-adaptive microprocessor control.
• Units include a hydronic module integrated into the chassis, limiting installation to
connection of power supply, water supply and return piping/air distribution ducting.
• Low-noise scroll compressors with low vibration level.
• Vertical condenser coils with protection grilles on anti-vibration mountings.
• Low-noise fans, now even quieter. Rigid fan installation for reduced start-up noise.
• Easy duct connection and fans with 80 Pa available pressure.
• The unit has a small footprint and is enclosed by easily removable panels.
• Simplified electrical connections.
• Systematic operation test before shipment and quick-test function for stepby-step verification of the instruments, electrical components and motors.
• Maintenance-free scroll compressors and fast diagnosis of possible incidents
and their history via the Pro-Dialog+ control reduce maintenance costs.
• Leak-tight refrigerant circuit.
• Corrosion resistance tests, accelerated ageing test on compressor piping and fan
supports and transport simulation test on a vibrating table in the laboratory.
\\MAINMENU\STATUS
CAPB_T
DEM_LIM
SP
CTRL_PNT
EMSTOP
0
100
4.2
-28.9
dsable
%
%
°C
°C
Circuit B Total Capacity
START/STOP
ENTER
PRO-DIALOG+
Pro-Dialog+ operator interface
86
Hydronic module, sizes 026-033
