30RQ 017-033
Physical data
30RQ
Air conditioning application as per EN14511-3 : 2013
Condition 1/condition 2
Nominal cooling capacity
EER
Eurovent class, cooling (condition 1)
ESEER (condition 1)
Heating application as per EN14511-3:2013
Condition 1/condition 2
Nominal heating capacity
COP
Eurovent class, heating (condition 1)
Operating weight*
Standard unit with/without hydronic module
Refrigerant*
Compressor
Control
Fans
Air flow
Water heat exchanger
Air heat exchanger
Unit with hydronic module
Power input
Nominal operating current
Dimensions
Length x depth x height
017
021
026
033
16.0/22.2
3.17/4.02
A
3.61
20.2/27.4
3.11/3.76
A
3.44
26.7/34.3
3.01/3.62
B
3.36
32.7/43.6
3.21/3.96
A
3.58
kW
kW/kW
17.0/17.6
3.18/3.99
B
21.7/22.2
3.28/3.98
A
29.9/31.0
3.20/3.98
A
33.3/34.7
3.19/3.98
B
kg
kW
A
206/191
223/208
280/262
295/277
R-410A
One hermetic scroll compressor
Pro-Dialog+
Two twin-speed axial fans, 3 blades
One twin-speed axial fan, 7 blades
2217
1978
3530
3530
Plate heat exchanger
Copper tubes and aluminium fins
One single-speed pump, screen filter, expansion tank, flow switch, pressure gauge, automatic air purge valve, safety valve
0.54
0.59
0.99
1.10
1.30
1.40
2.40
2.60
mm
1136 x 584 x 1579
kW
kW/kW
kW/kW
l/s
1136 x 584 x 1579
1002 x 824 x 1790
1002 x 824 x 1790
NOTE: For the conditions please refer to page 73.
*
Weight shown is a guideline only. To f
