HIGH-TEMPERATURE AIR-TO-WATER
HEAT PUMPS
Heating
Heating
Accessories
•
•
•
•
•
JBus, BacNet and LonTalk gateways
Remote user interface
Master/slave operation
Hydronic module
Water filter
61AF
Features
• Two sizes with nominal heating capacities from 14 to 20 kW.
• The Aquasnap high-temperature heat pump range was designed for commercial
applications such as the heating of offices, apartments and hotels as well as
domestic hot water production in new and refurbished buildings.
• Units incorporate the latest technological features: scroll compressors with
vapour injection, low-noise fans made of a composite material, auto-adaptative
microprocessor control, electronic expansion valve and multi-speed pump.
• Units certified to the Eurovent energy efficiency class A with a COP of over 4
and comply with the COP required by the Ecolabel certification.
• 61AF heat pumps incorporate a hydronic module with a multi-speed pump,
as standard.
• Low noise levels and a very compact chassis reduce the noise disturbance
from the unit.
• The operating range allows outside temperatures down to -20°C and leaving
water temperatures up to 65°C for domestic hot water applications.
• Intelligent unit control permits unit operation in extreme cond itions,
minimising unit shut-down times.
• Systematic factory run test before shipment and quick-test function for
verification of instruments, electrical components and motors.
• Low-noise scroll compressors with low vibration level.
• Simplified electrical connections.
• Comprehensive quality and endurance tests.
\\MAINMENU\STATUS
CAPB_T
DEM_LIM
SP
CTRL_PNT
EMSTOP
0 %
100 %
4.2 °C
-28.9 °C
dsable
Circuit B Total Capacity
START/STOP
ENTER
PRO-DIALOG+
Pro-Dialog+ operator interface
80
