80HMA
Physical data
Indoor unit (comfort module)
Number of comfort zones
Electric booster element
Number of auxiliary heating steps
Connection of back-up boiler
Dimensions, H x L x D
Operating weight
Power supply
Recommended circuit breaker size
kW
mm
kg
V-ph-Hz
80HMA-M00
1
0
1 (external boiler)
Yes
800 x 450 x 320
34
230-1-50
C6
80HMA-M03
1
3
1
No
800 x 450 x 320
35
230-1-50
C20
80HMA-M06
1
6
3
No
800 x 450 x 320
35
230-1-50
C32
80HMA-T06
1
6
3
No
800 x 450 x 320
35
400-3-50
C16
80HMA-T09
1
9
3
No
800 x 450 x 320
35
400-3-50
C20
Combination table, indoor and outdoor units
Outdoor unit (heat pump)
30AWH04HC
30AWH06HC
30AWH08HC
30AWH12HC
30AWH12HC9
30AWH15HC
30AWH15HC9
Nominal capacity 4 kW
Nominal capacity 6 kW
Nominal capacity 8 kW
Nominal capacity 12 kW
Nominal capacity 12 kW
Nominal capacity 15 kW
Nominal capacity 15 kW
Indoor unit (comfort module)
80HMA-M00
80HMA-M03
80HMA-M06
80HMA-T06
80HMA-T06
80HMA-T09
80HMA-T09
Reversible, 1 zone, maximum heating capacity 20 kW for boiler back-up application
Reversible, 1 zone, maximum heating capacity 20 kW with 3 kW 1-phase electrical heater booster
Reversible, 1 zone, maximum heating capacity 20 kW with 6 kW 1-phase electrical heater booster
Reversible, 1 zone, maximum heating capacity 20 kW with 6 kW 3-phase electrical heater booster
Reversible, 1 zone, maximum heating capacity 20 kW with 6 kW 3-phase electrical heater booster
Reversible, 1 zone, maximum heating capacity 20 kW with 9 kW 3-phase electrical heater booster
Reversible, 1 zone, maximum heating capacity 20 kW with 9 kW 3-phase electrical heater booster
NOTE: All 30AWH sizes are compatible with the 80HMA comfort module range. Comfort module controls can also manage up to eight 30AWH units. A parallel hydronic coupling of the unit to a tank is necessary
(field supply). 30RQ 017 to 021 and 61AF 014 to 019 units are also compatible, but the water volume of this installation must be checked by a professional and comply with the heat pump size minimum
requirements. Depending on the terminal unit type installed with the Carrier system a buffer tank may have to be added.
Electrical data
Comfort module 80HMA
Power supply
Voltage range
Max. power consumption, board and auxiliary devices
Board and auxiliary circuit breaker protection (not included)
Electric heater power consumption
Electric heater circuit breaker protection (not included)
Max. operating current
Main power cable size
Communication cable (FROH2R)
User interface (additional or remote) cable (FROH2R)
Booster heater power supply cable (H05VV-F)
Booster heater activation cable (FROH2R)
Domstic hot water sensor cable (FROH2R)
Remote outdoor sensor cable (FROH2R)
V-ph-Hz
V
kW
kW
A
mm2
mm2
mm2
mm2
mm2
mm2
mm2
M00
230-1-50
207-253
1.15
C6
0
C6
5
3G x 2.5
2 x 0.75
4 x 0.75
3G x 2.5
2x1
2 x 0.5
2 x 0.5
M03
230-1-50
207-253
1.15
C6
3
C20
18
3G x 4
2 x 0.75
4 x 0.75
3G x 2.5
2x1
2 x 0.5
2 x 0.5
M06
230-1-50
207-253
1.15
C6
6
C32
31
3G x 6
2 x 0.75
4 x 0.75
3G x 2.5
2x1
2 x 0.5
2 x 0.5
Note: The heat pump data depends on the heat pump used.
Operating limits
Heat pump limits
Comfort module limits
Indoor temperature
Water temperature, cooling
Water temperature, heating
Depends on the heat pump selected
5-30°C
4-18°C
20-80°C
79
T06
400-3-50
360-400
1.15
C6
6
C16
14
5G x 2.5
2 x 0.75
4 x 0.75
3G x 2.5
2x1
2 x 0.5
2 x 0.5
T09
400-3-50
360-400
1.15
C6
9
C20
18
5G x 4
2 x 0.75
4 x 0.75
3G x 2.5
2x1
2 x 0.5
2 x 0.5
