42GR ATM
Physical data
42GR
Size 1.9
Fan
109 (394)
Air flow
l/s (m3/h)
Pressure drop
Pa
395
Cooling mode
Total cooling capacity
kW
3.07
Sensible cooling capacity
kW
2.21
Water flow rate
l/s (l/h)
0.14 (504)
Water pressure drop
kPa
34
2-pipe heating mode
Heating capacity
kW
3.09
4-pipe heating mode
Heating capacity
kW
2.92
Water flow rate
l/s (l/h)
0.07 (251)
Water pressure drop
kPa
12
Electric heater
Low-capacity heating
W
450
High-capacity heating
W
1700
Sound levels
Sound power level
dB(A)
74
Sound pressure level*
dB(A)
53
NR value
48
V-ph-Hz
230-1-50
Power supply
Power input
W
133
Current draw
A
0.64
Dimensions
Coil inlet/outlet diameters
in
1/2 gas
Length
mm
960
Height
mm
962
Depth
mm
250
kg
35
Weight
Based on Eurovent rating standards:
Cooling: Entering/leaving air temperature = 27°C db/19°C wb – entering/leaving water temperature = 7°C/12°C.
Heating (2 pipes): Entering air temperature = 20°C – entering water temperature = 50°C, same water flow rate as in cooling.
Heating (4 pipes): Entering air temperature = 20°C – entering/leaving water temperature = 70°C/60°C.
*
Based on a hypothetical acoustic attenuation for the room and the air distribution system of -21 dB(A).
Dimensions, mm
Size 2.9
103 (371)
250
3.14
2.20
0.21 (752)
52
3.20
3.54
0.08 (305)
19
450
1800
66
45
40
230-1-50
126
0.91
1/2 gas
960
962
420
50
Air distribution with Optimix linear diffusers
Standard installation
Cooling air flow
Supply air
n
sio
en
sp ng
Su casi
Return air
Fresh
air
inlet
Heating air flow
Controller
117
