air treatment modules
Air treatment
42GR
Options/accessories
• Custom-made product on request
Standard controls
NTC communicating controller
• Network communication
• Aquasmart Evolution system
compatible
• IAQ and DCV management
• Motorised blinds and lighting
control
Aquasmart New System Manager
Features
• Two sizes with two-pipe plus electric heater or four-pipe coils, with an air flow
range from 103 to 109 l/s, a cooling capacity of 3.1 kW and a heating capacity
range from 2.9 to 3.5 kW.
• Decentralised compact ducted chilled-water fan coil system, designed for
installation in plant rooms. This allows centralised service and maintenance.
• Reliable and efficient heating and cooling for office blocks and institutional
buildings.
• High efficiency EU6 filter.
• Extremely low sound level.
• The LEC (low energy consumption) fan motor assembly is available as standard.
This direct-drive motor is electronically commutated (EC motor), controlled by
a 0–10 V signal and allows precise, simple and quiet unit operation in a wide
range of rotational speeds in variation from the original speed.
• High-pressure centrifugal fans, compatible with air diffusion systems up to
300 Pa.
• Compatible with the 35BD air diffuser range.
• Safe factory-installed electric heater for single or two-stage hot water heating.
• Available with demand control ventilation (DCV) and CO2 sensor.
• Can be equipped with a UV-PCO IAQ module.
• Low hydraulic pressure drop with a valve mounted, compatib
