mente posizionata dall ' operatore e ruotata una volta per ogni lato lavorato. I vantaggi di questo sistema sono concreti: non necessita di molti cambi utensile come la pressa, riduco al minimo lo sforzo, mi servono operatori specializzati e ottengo una ripetibilità del pezzo molto più alta. È però giusto dirlo: pur sembrando potenzialmente in grado di risolvere tutti i problemi, in realtà va affiancata alle tecnologie già presenti. Rispetto a una presso piegatrice non copre tutti gli spessori, la tangenziale arriva fino a 6 mm, e non copre tutte le lunghezze; rispetto alla pannellatrice ha una cadenza produttiva più bassa. È quindi davvero una terza via: una tecnologia ibrida che racchiude la flessibilità della presso piegatrice e la filosofia di lavorazione di una pannellatrice ».
I vantaggi della piegatura tangenziale Merlino ha poi spiegato come « più grossi sono i pezzi da piegare, più, effettivamente, convenga pensare a una macchina a bandiera, fermo restando, i limiti di spessore lavorabile. Il vantaggio non è solo geometrico: si gioca proprio sulla gestione pezzo durante la lavorazione. Su una piegatrice un pezzo di grandi dimensioni ha bisogno di più operatori, e quando piego di testa un pezzo lungo posso avere bisogno del carroponte. Con le nostre macchine, invece, l ' operatore è sempre unico e il pezzo è sempre appoggiato: non si muove nello spazio. L ' operatore è relegato alla semplice rotazione del pezzo quando termina il ciclo di piegatura su un lato. Da qui arriva l ' efficienza sullo sforzo fisico: lavorazioni che richiederebbero due o più operatori si fanno con un solo uomo, e in maniera semplice. Significa dire basta, basta ribaltare la lamiera, basta accompagnare i pezzi in aria. L ' operatore produce meglio, più velocemente, da solo, e soprattutto non si affatica e usura le spalle, perché non deve più accompagnare il pezzo. Tutto questo porta con sé ergonomia e sicurezza: il fattore umano è ormai una delle discriminanti più importanti, e poter produrre pannelli grandi con operatori anche poco esperti è un grande vantaggio. Sul piano del rischio, poi, l ' operatore non interviene dentro gli organi in movimento della macchina, e ciò porta un grado di sicurezza molto più alto rispetto alla piegatrice. E lo facciamo con una macchina elettrica, che ha consumi davvero interessanti, decisamente ridotti rispetto a una piegatrice: quindi, oltre a tutti questi vantaggi, anche un costo energetico per pezzo più basso ».
L’ importanza della formazione L’ intervento di Merlino ha introdotto la figura del piegatore; abbiamo quindi chiesto a Samuele Banassi di parlarci della ormai cronica mancanza di manodopera specializzata e di come ciò possa influire sull’ efficienza produttiva. « Influisce enormemente,- afferma Samuele- ma anche in questo caso bisogna partire da una premessa. Anche il migliore dei piegatori lavora su pezzi che qualcuno ha progettato prima di lui. Se lo sviluppo non è corretto, se il pezzo presenta criticità di fattibilità o se il disegno non è stato pensato correttamente per essere piegato, una parte importante dei problemi nasce ancora prima che il materiale arrivi in macchina. In ufficio tecnico serve personale preparato, anzi: per questo sostengo che il primo piegatore è in ufficio tecnico. Detto ciò, un buon piegatore deve saper leggere un disegno, scegliere gli utensili corretti e verificare come fare il pezzo ancora prima di cominciare ad attrezzare la macchina. Deve inoltre gestire la variabilità continua che la lamiera restituisce per sua natura, in modo da avere il pezzo finito all’ interno delwith even greater configuration potential. We offer these platforms in a wide range of sizes specifically tailored to the final application, starting from the part, the production mix, the destination sector and the client ' s goals. This is where the concept of a tailored approach comes in. The technology is consolidated and many options are shared across the platforms. I ' m thinking of the CLA tools for auxiliary bends and complex geometries, the P tools for advanced applications, or the CUT option, which enables the cutting of profiles and transforms the panel bender into a true manufacturing centre. This approach is particularly appreciated by subcontractors. By definition, subcontractors must be flexible, so they often request extensive configurations to expand the machine ' s application range and cover diverse order types, both today and in the future, without‘ stiffening’ the process. Furthermore, both platforms can evolve in terms of automation. P-Robot was created specifically to extend the flexibility and productivity of the panel bender, while simplifying programming and usability. It’ s a modular solution that can operate in different modes, automatic or mixed and can be installed on all our panel benders. And then there is one last, very important point: today, panel bending no longer stops at the perimeter of the bend but in general is increasingly becoming part of broader projects. P4, for example, can be integrated into manufacturing lines, such as the S4 + P4, designed for continuous, streamlined production without intermediate handling. P2 is often part of our flexible smart job shops( FSJ), where technology, software, automation, robotics and artificial vision work together to manage dynamic and highly variable production. Offering panel bending platforms today confirms how central the panel bending process is in a modern workshop. Not as a niche technology, but as a powerful lever to increase flexibility, simplify work and slash the cost per part.”
TANGENTIAL BENDING Piero Merlino then emphasised the pioneering role of Evomach in the development of tangential bending, a hybrid technology that sits somewhere between press braking and panel bending and therefore brings several aspects with it that make it extraordinarily efficient. " Tangential bending is a hybrid technology that straddles press braking and panel bending. It incorporates some principles from both approaches and has its own characteristics that make it suitable for the typical processes performed in many sheet metal shops. The operating principle is different from that of a traditional press brake. In tangential bending, the sheet metal doesn ' t move during the process because it ' s the tool that performs bending, both positive and negative. The sheet metal panel isn ' t flipped; it ' s simply positioned by the operator and rotated once for each side being bent. The benefits of this system are tangible: it doesn ' t require as many tool changes as a press brake, the effort is minimised, skilled operators are not needed and much higher repeatability is achieved. It ' s fair to say, however, that while tangential bending seems potentially capable of solving all problems, it actually needs to be supported by existing technologies. Compared to a press brake, it doesn ' t cover all thicknesses— tangential bending reaches up to 6 mm— and it doesn ' t cover all lengths. Compared to a panel bender, it offers lower production rates. Therefore, tangential bending is truly a third option— a hybrid technology that combines the flexibility of a press brake with the process vision of a panel bender.”
THE ADVANTAGES OF TANGENTIAL BENDING Merlino then explained that " the larger the pieces to be bent, the more convenient it is to install a jib type tangential bender, while still respecting the workable thickness limits. The advantage isn ' t just geometric: it depends on the way the piece is handled during the process. On a press brake, a large piece requires multiple
