Endmills Carbide, 6-8 Flute, R50/35 NH, Cnr Rad, Long Reach, Harmony
- VHM-ULTRA grade of carbide for high performance
- For super fine finishing applications
- 50/35° variable flute helix for chatter free milling
- Suitable for hard, short chipping materials up to 48 HRC
- AlCrN for longer tool life
r
+
6º
Catalogue Code
Discount Group
Material
Surface Finish
Sutton Designation
Geometry
Shank Form (DIN 6535)
Shank Tolerance
Size Ref.
d 1 (e8)
0605
0610
0805
0810
1005
1010
1015
1020
1205
1210
1215
1220
1605
1610
1615
1620
2005
2010
2015
2020
VHM-ULTRA VHM-ULTRA
AlCrN AlCrN
NH NH
R50/35 R50/35
HA HB
h5 h5
l 1 l 2 d 2 z rad Item # Item #
13 6 6 0.5 62 13 6 6 1.0 68 19 8 6 0.5 68 19 8 6 1.0 80 22 10 6 0.5 80 22 10 6 1.0 80 22 10 6 1.5 80 22 10 6 2.0 93 26 12 6 0.5 93 26 12 6 1.0 93 26 12 6 1.5 93 26 12 6 2.0 108 32 16 6 0.5 108 32 16 6 1.0 108 32 16 6 1.5 108 32 16 6 2.0 126 38 20 8 0.5 126 38 20 8 1.0 126 38 20 8 1.5 126 38 20 8 2.0 E436 0605
E436 0610
E436 0805
E436 0810
E436 1005
E436 1010
E436 1015
E436 1020
E436 1205
E436 1210
E436 1215
E436 1220
E436 1605
E436 1610
E436 1615
E436 1620
E436 2005
E436 2010
E436 2015
E436 2020 E437 0605
E437 0610
E437 0805
E437 0810
E437 1005
E437 1010
E437 1015
E437 1020
E437 1205
E437 1210
E437 1215
E437 1220
E437 1605
E437 1610
E437 1615
E437 1620
E437 2005
E437 2010
E437 2015
E437 2020
8.0
10.0
12.0
