Endmills Carbide, 6-8 Flute, R50 / 35 NH, Extra Long, Harmony
- VHM-ULTRA grade of carbide for high performance- For super fine finishing applications- 50 / 35 ° variable flute helix for chatter free milling- Suitable for hard, short chipping materials up to 48 HRC- AlCrN for longer tool life
45 º
6 º
Catalogue Code
E434
E435
Discount Group
B0210
B0210
Material
VHM-ULTRA
VHM-ULTRA
Surface Finish
AlCrN
AlCrN
Sutton Designation
NH
NH
Geometry
R50 / 35
R50 / 35
Shank Form( DIN 6535)
HA
HB
Shank Tolerance
h5
h5
Size Ref.
d 1
( e8)
l 1
l 2
d 2
z
Item #
Item #
0600
6.0
62
18
6
6
E434 0600
E435 0600
0800
8.0
68
24
8
6
E434 0800
E435 0800
1000
10.0
80
30
10
6
E434 1000
E435 1000
1200
12.0
93
36
12
6
E434 1200
E435 1200
1600
16.0
108
48
16
6
E434 1600
E435 1600
2000
20.0
126
60
20
8
E434 2000
E435 2000
2500
25.0
150
85
25
8
E434 2500
E435 2500
