11-48
Maintenance and service/Replacing bulbs
2. Remove the bulb from the headlight
assembly by turning it counterclockwise.
3. Replace the bulb with a new one. At
this time, use care not to touch the bulb
surface.
4. To install the bulb to the headlight
assembly, turn it clockwise until it clicks.
5. Left-hand side: Set the washer fluid
filler pipe to the original place and secure it
with a clip.
Right-hand side: Install the air intake
duct with clips.
& Front fog light (models with-
out the LED front fog light) (if
equipped)
NOTE
It may be difficult to replace the bulbs.
Have the bulbs replaced by your
SUBARU dealer if necessary.
2. Turn over the mud guard.
& Front fog light (models with
the LED front fog light)
Have the front fog light assembly checked
by your SUBARU dealer.
1. Remove the clips.
3. Disconnect the electrical connector
from the bulb as pushing the tab.
