Maintenance and service/Replacing bulbs
11-49
1. Remove the clips from the trunk trim
with a flat-head screwdriver.
4. Remove the bulb by turning it counter-
clockwise.
5. Replace the bulb with a new one.
6. Reattach the mud guard.
& Rear combination lights
2. Open the rear portion of the trunk trim
panel as illustrated.
NOTE
Make sure that the “ * ” part of the trunk
trim in the illustration does not contact
the trunk lid stay. If the “ * ” part is bent,
the trunk trim may be torn.
1)
2)
3)
Rear side marker light
Backup light
Rear turn signal light
3. Remove the bulb socket from the rear
combination light assembly by turning it
counterclockwise.
4. Pull the bulb out of the bulb socket and
replace it with a new one.
5. Set the bulb socket into the rear
combination light assembly and turn it
clockwise until it locks.
6. Secure the rear trunk trim panel with
the clips.
NOTE
When replacing a bulb of the rear side
marker light, detach the bulb socket of
the backup light in advance. After
– CONTINUED –
