3-38
Instruments and controls/Combination meter display (color LCD)
4)
Combination meter display
(color LCD)
5)
WARNING
6)
7)
Always pay adequate attention to
safe driving when operating the
combination meter display (color
LCD) while the vehicle is in motion.
When operation of the combination
meter display (color LCD) interferes
with your ability to concentrate on
driving, stop the vehicle before
performing operations on the
screen. Also, do not concentrate
on the display while driving. Doing
so may cause you to look away from
the road and could result in an
accident.
Various information will be shown on the
combination meter display (color LCD).
Also, a warning message will appear on
the display if a malfunction, etc. is
detected. In addition, several settings for
the displayed content can be performed.
Warning indication (refer to “Warning
indication” F3-41.)
Select lever/gear position indicator (refer
to “Select lever/gear position indicator
(CVT models)” F3-34.)
SI-DRIVE indicator light (refer to “SI-
DRIVE indicator” F3-34.)
Odometer (refer to “Odometer” F3-9.)/
double trip meter (refer to “Double trip
meter” F3-9.)
Control switch
1) Up (select)
/SET (enter)
2)
3) Down (select)
Combination meter display (color LCD)
1) ECO gauge (refer to “ECO gauge” F3-
11.)
2) Warning screen (refer to “Warning
screen” F3-39.)/Basic screen (refer to
“Basic screens” F3-40.)
3) Cruise control information display/
C.DIFF/DCCD indicator
