Instruments and controls / Warning and indicator lights 3-37
! Warning indicator
All the indicators will flash when the driver’ s control center differential has a malfunction. Have the vehicle inspected by your SUBARU dealer. For details, refer to“ Driver’ s Control Center Differential( C. DIFF / DCCD)( STI)” F7-18.
If a malfunction occurs in the vehicle( for example, when the rear differential oil becomes hot), all of the indicators may disappear. In this case, the setting value for the initial limited slip differential( LSD) torque of the driver’ s control center differential( C. DIFF / DCCD) will be cancelled. However, it does not indicate a malfunction of the C. DIFF / DCCD itself.
& REV indicator light( STI)
This indicator light illuminates when the engine speed reaches the level that was previously set. This indicator light also flashes when the tachometer needle enters the red zone. For details, refer to“ REV indicator light and buzzer( STI)” F3- 12.
& Steering Responsive Headlight warning indicator / Steering Responsive Headlight OFF indicator( if equipped)
This indicator appears when the Steering Responsive Headlight is deactivated. Also, the indicator flashes when a malfunction occurs in the Steering Responsive Headlight. Refer to“ Steering Responsive Headlight( SRH)” F3-69.
& BSD / RCTA warning indicator( if equipped)
This warning indicator appears when the BSD / RCTA is malfunctioning. In this case the BSD / RCTA warning indicator will be shown on the combination meter display( color LCD). When this indicator appears, have your vehicle inspected by your
SUBARU dealer as soon as possible.
& BSD / RCTA OFF indicator( if equipped)
The indicator appears when the BSD / RCTA is deactivated. In this case the BSD / RCTA OFF indicator will be shown on the combination meter display( color LCD). For details, refer to“ BSD / RCTA” F7-57.
& RAB warning indicator( if equipped)
This indicator illuminates if the Reverse Automatic Braking System malfunctions. Refer to“ Reverse Automatic Braking System” F7-66.
& RAB OFF indicator light( if equipped)
This indicator illuminates when the Reverse Automatic Braking System is turned OFF, or when the Reverse Automatic Braking System is suspended temporarily. Refer to“ Reverse Automatic Braking System” F7-66.
