3-36
Instruments and controls/Warning and indicator lights
. when the light switch is turned to the
” or “ ” position
“
. when the light control switch is in the
“AUTO” position and the headlights illumi-
nate automatically
& Driver’s control center differ-
ential auto indicator (STI)
! Driver’s control center dif-
ferential auto [+] indicator
(STI) & Driver’s control center differ-
ential indicator and warning
(STI)
When the AUTO [+] mode is set, the
AUTO [+] indicator appears.
For details, refer to “Driver’s Control
Center Differential (C.DIFF/DCCD) (STI)”
F7-18.
! Driver’s control center dif-
ferential auto [−] indicator
(STI) ! Indicator
When the AUTO [−] mode is set, the
AUTO [−] indicator appears.
For details, refer to “Driver’s Control
Center Differential (C.DIFF/DCCD) (STI)”
F7-18.
This indicator functions while the ignition
switch is “ON”. When it appears, it
indicates that the driver’s control center
differential is set to the auto mode. It
disappears when the driver’s control
center differential is set to the manual
mode. For details, refer to “Driver’s Con-
trol Center Differential (C.DIFF/DCCD)
(STI)” F7-18.
When you select the manual mode of the
driver’s control center differential, these
indicators will appear. They indicate the
initial limited slip differential (LSD) torque
that is currently selected for the center
differential.
