Subaru WRX & WRX STI Manuals 2018 WRX & WRX STI Owner’s Manual | Page 177

Instruments and controls/Combination meter display (color LCD)
& Basic operation
Pull “ ” or “ ” of the control switch
toward you to switch the screens and
selection items. Pull the “ /SET” switch
toward you to select and set the item.
If there are some useful messages, such
as vehicle information, warning informa-
tion, etc., they will interrupt the current
screen, and appear on the display accom-
panied by a beep. If such a screen is
displayed, take proper action according to
the message shown on the screen.
The warning screen will return to the
original screen after a few seconds. While
the “ ” information reminder is shown on
the display, it may be possible to display
the warning screen again. To recall the
message marked with “ ” on the display,
pull the “ /SET” switch toward you.
& Welcome screen and Good-
bye screen
3-39
& Warning screen
When the driver’s door is opened and
closed after unlocking the door, the
Welcome screen will appear on the
combination meter display (color LCD)
for approximately 20 seconds.
When the ignition switch is turned to the
“LOCK”/“OFF” position, the combination
meter display (color LCD) gradually turns
off (Good-bye screen).
NOTE
. Once the Welcome screen appears,
it takes a certain period of time to
display it again.
. The Welcome screen will disappear
after turning the ignition switch to the
“ON” position while the Welcome
screen is displayed.
. If you open any of the doors while
the Welcome screen is displayed, the
door ajar warning will appear.
. You can set the Welcome screen
and Good-bye screen to on or off. For
details, refer to “Welcome Good-bye
Screen” F3-43.
Example of warning
If a warning or a malfunction is detected, a
message will appear. Take the appropriate
actions based on the messages indicated.
– CONTINUED –
