3-50

Instruments and controls/Multi function display

temperature has increased to 418F
(58C) or higher.

and time setting” F3-60.

! Top display
One of the following items can be displayed on the top display.
. Average fuel consumption corresponding to the driving distance of each trip
meter
. Current fuel consumption (This may
not be displayed when driving at a low
speed.)
. Driving range on remaining fuel

If the vehicle battery is disconnected,
the clock shown in the information bar
will be reset. Set the time again after
the vehicle battery is connected. For
details about the setting, refer to “Top
display setting” F3-69.

For details about the setting of the top
display, refer to “Top display setting” F369.

NOTE
The driving range on the remaining fuel
is calculated using the average fuel
consumption of the last 19 miles (30
km) driven. This value may be different
from the values calculated using the
average fuel consumption corresponding to the driving distance of each trip
meter or the current fuel consumption.
! Clock
The clock can be displayed in either 12hour display or 24-hour display. For details
about the setting, refer to “Current date

NOTE

! Boost pressure + accelerator
opening ratio screen

1)
2)
3)
4)
5)
6)

Boost pressure (digital display)
Boost pressure (analog display)
Accelerator opening ratio (digital display)
Accelerator opening ratio (analog display)
The peak value of the boost pressure
(digital display)
The peak value of the boost pressure
(analog display)

This screen displays the boost pressure,
the accelerator opening ratio and the peak
value of the boost pressure in both digital
and analog format. Pressing the
button in the “Boost pressure + accelerator opening ratio screen” moves to a
screen where you can reset the peak
value of the boost pressure.
