Instruments and controls/Multi function display

& Basic screens

3-49

! Information bar

These are the basic screens of the multi
function display.
Item

Page

Information bar

3-49

Boost pressure + accelerator
opening ratio screen

3-50

Fuel consumption screen

3-51

ECO history screen

3-51

Vehicle activation status
screen

3-52

Triple meter screen

3-53

Icy road surface warning screen

Guidance screen

3-53

Clock/calendar screen

3-54

Audio screen (if equipped)

3-54

By operating the “ ” or “ ” of the control
switch, you can switch the screen that is
always displayed. Also, when the
button is pushed and held, the selection
screen can be displayed. For details about
the selection screen, refer to “Selection
screen” F3-56.

1)
2)
3)
4)

Information bar
Outside temperature indicator
Top display
Clock

While the ignition switch is in the “ACC” or
“ON” position, the outside temperature
indicator, clock, etc. will be shown on the
information bar.
! Outside temperature indicator
This displays the outside temperature
between −408F (−408C) and 1228F
(508C).

When the outside temperature becomes
378F (38C) or less, the icy road surface
warning screen interrupts to inform the
driver that the road surface may be frozen.

NOTE
. The outside temperature indicator
shows the temperature around the
sensor. Therefore, the temperature indication may differ from the actual
outside air temperature.
. The icy road surface warning screen
should be treated only as a guide. Be
sure to check the condition of the road
surface before driving.
. Once the icy road surface warning
screen is displayed, it will not be
displayed again unless the outside
– CONTINUED –
