Instruments and controls

! Driver’s control center differential auto [−] indicator
light

! Warning light

3-25

Clock

When the AUTO [−] mode is set, the
AUTO [−] indicator light illuminates.
For details, refer to “Driver’s Control
Center Differential (DCCD) (STI)” F7-18.

& Driver’s control center differential indicator and warning
lights (STI)
! Indicator lights
All the indicator lights will flash in the event
that the driver’s control center differential
has a malfunction. Have the vehicle
inspected by your SUBARU dealer. For
details, refer to “Driver’s Control Center
Differential (DCCD) (STI)” F7-18.

& REV indicator light
(STI)

When you select the manual mode of the
driver’s control center differential, the
initial limited slip differential (LSD) torque
that is currently selected for the center
differential is indicated by the illumination
of these indicator lights.

The time changes by 1 minute each time
the “+” button or “−” button is pressed.
Pressing the “+” button moves the displayed time forward, while pressing the “−”
button moves the displayed time back.
Pressing and holding either button
changes the displayed time continuously.

This light illuminates when the engine
speed reaches a level set by driver or
when the tachometer needle enters the
red zone.

– CONTINUED –
