2-2 . Charging
107 cle Settings ”, and then press and hold .
3 Press or of the meter
control switches to select “ Charging Settings ”, and then
press .
The “ Charging Settings ” screen will be displayed .
4 Press or of the meter
control switches to select “ Charging Current ”, and then
press .
The “ Charging Current ” screen will be displayed .
5 Press or of the meter control switches to select “ 16A ” or “ 8A ” and then press .
● Setting operations on multimedia
1 Select . 2 Select “ Vehicle customize ”. 3 Select “ Charging ”. 4 Select “ Charging current ”. 5 Select “ 16A ” or “ 8A ”.
The maximum charging current is limited to less than or equal to the
selected current . *
If the breaker still trips while
charging , even after changing the upper limit of the charging current , check if the connected power
source meets the specified charging conditions . ( �P . 95 ) * : Restricting the charging current
will lengthen the charging time .
■ Changing the “ Charging Limit ” settings
The upper limit of the charge capacity can be changed in “ Vehicle Settings ” on the multi-information display or multimedia .
The selected upper limit value is common to AC charging and DC charging .
● Setting operations on multi-information display
1 Press or of the meter control switches to select .
2 Press or of the meter
control switches to select “ Vehicle Settings ”, and then press and
hold .
3 Press or of the meter
control switches to select “ Charging Settings ”, and then
press .
The “ Charging Settings ” screen will be displayed .
4 Press or of the meter
control switches to select “ Charging Limit ”, and then press
.
The “ Charging Limit ” screen will be displayed .
5 Select “ Full ”, “ 90 %”, “ 80 %”, “ 70 %”, “ 60 %” or “ 50 %” and then
press .
● Setting operations on multimedia
1 |
Select |
. |
2 |
Select “ Vehicle customize ”. |
3 |
Select “ Charging ”. |
4 |
Select “ Charging limit ”. |
5 |
Select “ Full ”, “ 90 %”, “ 80 %”, |
“ 70 %”, “ 60 %” or “ 50 %”. |
If the setting is changed during DC |
charging , charging may stop due to |
the operation of the DC charger |
timer and the traction battery cannot |
be fully charged . |
2
Electric Vehicle system
