INSTRUMENTS AND CONTROLS 159
The odometer shows the total distance that the vehicle has been driven.
NOTE
If you press the TRIP RESETswitch when the ignition switch is in the“ OFF” or“ ACC” position, the odometer / trip meter will light up. The indicators will turn off when the TRIP RESET switch is not operated for approximately 10 seconds.
DOUBLE TRIP METER
TRIP RESET switch Trip meter s03ad05
S _ 308339-W
This meter displays the two trip meters when the ignition switch is in the“ ON” position.
The trip meter shows the distance that the vehicle has been driven since you last set it to zero.
The display can be switched as shown in the following sequence by pressing the TRIP RESET switch.
CAUTION
To ensure safety, do not attempt to change the function of the indicator during driving, as an accident could result.
NOTE
. If the connection between the instrument cluster and battery is broken for any reason such as vehicle maintenance or fuse replacement, the data recorded on the trip meter will be lost.
. If you press the TRIP RESET switch when the ignition switch is in the“ OFF” or“ ACC” position, the odometer / trip meter will light up. It is possible to switch between the A trip meter and B trip meter indications while the odometer / trip meter is lit up. In addition, it is possible to reset the trip meter by pressing and holding the TRIP RESET switch. The indicators will turn off when the TRIP RESET switch is not operated for approximately 10 seconds.
FUEL GAUGE AND DRIVING RANGE ON REMAINING FUEL s03ad07
3
ZOM0972
To reset the trip meter, select either the A trip or B trip meter, then press and hold the TRIP RESET switch.
S _ 308340-W
The fuel gauge shows the approximate amount of fuel remaining in the tank.
The gauge may move slightly due to fuel level movement in the tank( e. g., during braking, turning or acceleration).
– CONTINUED –
