160 INSTRUMENTS AND CONTROLS
NOTE
. You will see the“” sign in the fuel gauge. This indicates that the fuel filler lid is located on the right side of the vehicle.
. If you press the TRIP RESET switch while the ignition switch is in the“ OFF” or“ ACC” position, the fuel gauge will light up and indicate the amount of fuel remaining in the tank. The gauge will turn off when the TRIP RESET switch is not operated for approximately 10 seconds.
. The driving range on the remaining fuel is only a guide. The indicated value may differ from the actual driving range on the remaining fuel, so you must immediately fill the tank when the low fuel warning light illuminates.
. If you refuel the vehicle with approximately 2.6 US gal( 10 liters, 2.2 Imp gal) or less of fuel, the values indicated on the fuel gauge and driving range on the remaining fuel may not update. As a guideline, refueling the vehicle with approximately 2.6 US gal( 10 liters, 2.2 Imp gal) or more of fuel will update the indicated values.
The coolant temperature will vary in accordance with the outside temperature and driving conditions.
We recommend that you drive moderately until the pointer of the temperature gauge reaches near the middle of the range. Engine operation is optimum with the engine coolant at this temperature range and high revving operation when the engine is not warmed up enough should be avoided.
CAUTION
If the pointer exceeds the normal operating range, safely stop the vehicle as soon as possible.
Refer to“ Engine Overheating” FP446.
INSTRUMENT CLUSTER SET- TINGS s03ad16
Instrument cluster settings can be set on the center information display. For details, refer to“ Displays” FP204.
ENGINE COOLANT TEMPERA- TURE GAUGE s03ad08
Normal operating range
S _ 308341-W
The temperature gauge shows engine coolant temperature when the ignition switch is in the“ ON” position.
