combination light assembly by turning it counterclockwise.
6. Pull the bulb out of the bulb holder and replace it with a new one.
7. Set the bulb holder into the rear combination light assembly and turn it clockwise until it locks.
|
|||||
4. Slide the rear combination light assembly straight rearward and remove it from the vehicle. |
8. Reinstall the rear combination light assembly by sliding the two-pronged part of the combination light assembly securely to each holder of the vehicle side. |
9. Tighten the upper and lower screws. 10. Reinstall the side cover.
& Backup Light
s11be06
! Legacy s11be0601
NOTE
It may be difficult to replace the bulbs. We recommend that you have the bulbs replaced by your SUBARU dealer if necessary.
1. Open the trunk.
|
Maintenance and Service
11
|
||
1 Rear turn signal light 2 Rear side marker light |
|||||
5. Remove the bulb holder from the rear |
|||||
– CONTINUED – |
