Mirrors 291 |
||||||||
|
! Camera calibration error
s03ap110602
|
When there is a camera calibration error, the warning indicators will appear as shown in the illustration.
When the warning indicators appear, operate the mode lever to select the mirror mode. In such a case, we recommend that you consult your SUBARU dealer for repair.
|
! Maintenance
s03ap1104
|
1 Camera
. Make sure to clean the Smart Rearview Mirror and the area around the camera regularly. If these parts are not clean, the screen cannot be seen clearly.
. Wipe off the Smart Rearview Mirror and the area around the camera by using a dry soft cloth. If the foreign matter cannot be removed, first wipe the area off using a wet soft cloth, and then wipe using a dry cloth.
. Do not use alcohol, benzine or thinner for cleaning. Doing so could result in discoloration, deterioration, or malfunction.
. Make sure to clean the rear camera lens regularly. When you clean the rear
|
camera lens, first soak a soft cloth with diluted mild detergent to wipe it off, and wipe using a dry cloth.
. During snowy weather, remove the accumulated snow from around the antenna, because snow interferes with the camera image on the mirror.
. When installing a roof box or a similar accessory, do not block the area in front of the camera lens to avoid interfering with the camera image on the mirror.
. When the Smart Rearview Mirror’ s visibility is poor because there is dirt or other foreign material adhering to the camera, switch to the original rearview mirror.
! Tips s03ap1105
. Do not use the display mode for a long time while the engine is not running. Doing so could result in the battery discharge.
. Do not install radio antennas around the Smart Rearview Mirror. Radio waves may disturb the Smart Rearview Mirror screen.
. Observe the following instructions. Not doing so could result in malfunction or the main mirror unit falling off. – Do not push the button too strongly or move the lever too forcibly. – Do not turn the main mirror unit
|
3
Instruments and Controls
|
|||
– CONTINUED – |
