290
Mirrors
NOTE
. When the ignition switch is turned to the“ LOCK”/“ OFF” position, auto dimming will not activate.
. When the display mode is selected, auto dimming will not activate.
! When the display mode malfunctions s03ap1106
! Vehicle communication error s03ap110601
Dimming mirror mode ON indicator
Dimming mirror mode OFF indicator
When turning the dimming mirror mode ON / OFF, the dimming mirror mode ON / OFF indicator will illuminate for 5 seconds.
When there is a vehicle communication error, the warning indicators will appear as shown in the illustration.
1 Mode lever 2 Left button 3 Center button 4 Right button
When the warning indicators appear, operate the mode lever to select the mirror mode. In such a case, we recommend that you consult your SUBARU dealer for repair.
If the mode does not change to the mirror mode even when operating the mode lever, the mode lever may have malfunctioned. In such a case, press and hold one of the left, center, or right buttons for 10 seconds. Then the mode will change to the mirror mode.
