292
Mirrors
more than 90 degrees. – Do not impact the main mirror unit. – Do not impact the camera or antenna.. If the screen is hard to see because of light, select the mirror mode.
. If LED lights or scattered reflections are caught in the camera, the screen may flicker. However, this is not a malfunction.
. If something moves rapidly near the camera, the display may not be able to catch the item. However, this is not a malfunction.
. If the display mode is used, the view of the rear will be different from the normal use of the inner mirror or the mirror mode. Do not rely solely on the Smart Rearview Mirror; check the rear visually if necessary. Pay attention to traffic conditions for safe driving.
. Adjust the brightness of the screen appropriately. If the screen is too bright, the driver’ s eyes may get tired while driving.
. The Smart Rearview Mirror sometimes becomes hot. However, this is not a malfunction.
. In the following cases, the color may not be clear. However, this is not a malfunction.
– The shown items are a very far distance away.
– The environmental conditions are very dark.
! To operate the compass feature s03ap1107
1 Left button 2 Center button 3 Right button
Press any of the left, center or right buttons to display the main menu. Select compass mode using the left button.
NOTE
The main menu cannot be displayed on the display while the select lever is in a position other than the“ P” position.
! To turn the compass feature on / off s03ap110701
1 Compass
Select“ ON” or“ OFF” using the center button.
