! Gate Operator / Canadian Programming s03ap110803
Canadian radio-frequency laws require transmitter remote signals to “ time-out ” ( or quit ) after several seconds of transmission , which may not be long enough for HomeLink to pick up the signal during programming . Similar to this Canadian law , some U . S . gate operators are designed to “ time-out ” in the same manner . The indicator LED on the hand-held remote will go off when the device times out , indicating that it has finished transmitting .
If you live in Canada or you are having difficulties programming a gate operator or garage door opener by using the programming procedures , replace “ Programming a New HomeLink Button ” step 3 with the following :
While the HomeLink indicator light is flashing orange , press and release (“ cycle ”) your device ’ s hand-held remote every two seconds until the HomeLink indicator light changes from orange to green . You may now release the hand-held remote button .
|
NOTE
If programming a garage door opener or gate operator , it is advised to unplug the device during the “ cycling ” process to prevent possible overheating .
Proceed with “ Programming a New HomeLink Button ” step 4 to complete .
! Using HomeLink s03ap110804
To operate , simply press and release the programmed HomeLink button . Activation will now occur for the trained device ( i . e . garage door opener , gate operator , security system , entry door lock , home / office lighting , etc .). For convenience , the handheld remote of the device may also be used at any time .
! Erasing HomeLink Buttons s03ap110805
1 . Press any of the left , center or right buttons to select the main menu . Select HomeLink menu using the left button .
2 . Select “ SET UP ” using the right button .
3 . Select “ Continue ” using the HomeLink left button .
4 . Select the “ Trash can icon ” using the HomeLink left button .
|
5 . To erase the program for the HomeLink button , select “ Clear ” using the HomeLink center button .
HomeLink is now ready to be programmed at any time beginning with “ Programming a new HomeLink button ” - step 1 .
|
