Front Seats 35
2. Adjust the outside mirror angle. For
details about the settings, refer to “Remote
control mirror switch” ☞P265.
3. Move the select lever to the “P”
position, then the outside mirror angle will
return to its original position.
4. Turn the ignition switch to the “OFF”/
“LOCK” position.
5. Hold the access key fob and press and
hold the “SET” button, then press the “ ”
button of the access key fob.
A chirp will sound once, and the reverse
tilt-down mirror angle will be registered.
NOTE
. Approximately 9 seconds after the
select lever is moved to any position
other than “R” position.
. The factory setting (default setting)
for this function is set as the front
passenger’s side mirror. The setting of
the driver’s side mirror operation can
be changed by a SUBARU dealer.
Contact your SUBARU dealer for details.
. The system stores the adjusted
mirror angle for approximately 45 seconds
after the ignition switch is turned
to the “OFF” position. Register the
mirror angle while the memory function
is available.
! Utilizing of memory position
registered with button “1” or “2”
s01aa020702
WARNING
Be sure to press the correct button
to retrieve your registered memory
position. If the seat position is not
optimum for you, it may adversely
affect your driving and may reduce
the effectiveness of the seatbelt.
That could result in an accident
involving serious injury or death.
1. Turn the ignition switch to the “ON”
position.
2. Put the select lever is in the “P” position
and apply the parking brake. Then press
button “1” or “2”.
A chirp will sound and the seat and angle
of the outside mirrors moves to the
registered position.
When the select lever is moved to the “R”
position, the outside mirror will move to the
registered reverse tilt-down position.
NOTE
. A retrieved seat position might deviate
as the function is used continuously
over time.
. A retrieved seat position might deviate
if you attempt to continue operating
the registered seat in the same
direction when the registered seat is
already at the farthest possible point of
adjustment in any direction.
. If a new position is registered to the
same button, the previously registered
memory position data will be deleted.
. If the vehicle battery is removed, the
registered memory position data will
not be deleted.
. When the button “1” or “2” is
pressed within 45 seconds after the
driver’s door is opened, the registered
memory position can be retrieved even
if the ignition switch is in the “LOCK” or
“OFF” position.
– CONTINUED –
1
Seat, Seatbelt and SRS Airbags
