Instruments and controls/Mirrors
the device during the “cycling” process to prevent possible overheating.
Proceed with “Programming a New
HomeLink® button” step 4 to complete.
! Using HomeLink®
To operate, simply press and release the
programmed HomeLink® button. Activation will now occur for the trained device
(i.e. garage door opener, gate operator,
security system, entry door lock, home/
office lighting, etc.). For convenience, the
hand-held remote of the device may also
be used at any time.
! Erasing HomeLink® buttons
To erase programming from the three
buttons (individual buttons cannot be
erased but can be “reprogrammed” as
outlined below), follow the step noted:
Press and hold the two outer HomeLink®
buttons for at least 10 seconds. The LED
indicator will change from continuously lit
to rapidly flashing. Release both buttons.
Do not hold for longer than 20 seconds.
HomeLink® is now ready to be programmed at any time beginning with
“Programming a New HomeLink® button”
- step 1.
! Reprogramming a Single
HomeLink® button
To program a previously trained button,
follow these steps:
1. Press and hold the desired HomeLink®
button. DO NOT release the button.
2. The indicator light will begin to slowly
flash orange after 20 seconds. The
HomeLink® button can be released at this
point. Proceed with “Programming a New
HomeLink® button” - step 3.
3. If you do not complete the programming of a new device to the button, it will
revert to the previously stored programming.
3-79
Range may be reduced by obstacles such
as houses or trees. You may have to slow
your vehicle speed to successfully receive
the garage door opener communication.
! Programming Two-Way Communication
! Garage Door Two-Way Communication
HomeLink® has the capability of communicating with your garage door opener.
HomeLink® can receive and display “closing” or “opening” status messages from
compatible garage door opener systems.
At any time, HomeLink® can also recall
and display the last recorded status
communicated by the garage door opener
to indicate your garage door being
“closed” or “opened”.
Within 5 seconds after programming a
new HomeLink® button, both of HomeLink’s garage door status indicators will
flash rapidly green indicating that the
garage door two-way communication has
been enabled. If your garage door status
indicators flashed, two-way communication programming is complete.
HomeLink® has the capability of receiving
this communication from the garage door
opener at a range up to 820 feet (250 m).
If the garage door status indicators do not
flash, additional HomeLink® information
and programming videos can be found
1)
Status Indicators
– CONTINUED –
