3-78
Instruments and controls/Mirrors
7. Return to the vehicle and firmly press,
hold for 2 seconds and release the
HomeLink® button up to three times. At
this point programming is complete and
your device should operate when the
HomeLink® button is pressed and released.
1)
Status Indicators
8. If status indicator arrows appear next
to the indicator light, please refer to
“Garage Door Two-Way Communication”
F3-79.
In the event that there are still programming difficulties or questions, additional
HomeLink® information and programming
videos can be found at
www.HomeLink.com and
www.youtube.com/HomeLinkGentex. For
Genie and Sommer garage door openers
please go directly to the H omeLink ®
website.
! Gate Operator / Canadian Programming
Canadian radio-frequency laws require
transmitter remote signals to “time-out”
(or quit) after several seconds of transmission, which may not be long enough for
HomeLink® to pick up the signal during
programming. Similar to this Canadian
law, some U.S. gate operators are designed to “time-out” in the same manner.
The indicator LED on the hand-held
remote will go off when the device times
out, indicating that it has finished transmitting.
If you live in Canada or you are having
difficulties programming a gate operator or
garage door opener by using the programming procedures, replace “Programming a
New HomeLink® button” step 3 with the
following:
While the HomeLink® indicator light is
flashing orange, press and release (“cycle”) your device’s hand-held remote
every two seconds until the HomeLink®
indicator light changes from orange to
green. You may now release the handheld remote button.
NOTE
If programming a garage door opener
or gate operator, it is advised to unplug
