3-80
Instruments and controls/Mirrors
. U.S.-spec. models
online at www.HomeLink.com and
www.youtube.com/HomeLinkGentex.
FCC ID: NZLAECHL5
! Using Two-Way Communication
CAUTION
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the
equipment.
1)
2)
1)
Status Indicator
Recall and display (at any time) the last
recorded garage door status message
communicated to HomeLink® by simultaneously pressing HomeLink® buttons 1
and 2 for 2 seconds. HomeLink® will
display the last recorded status for 3
seconds.
If two-way communication programming is
successful, HomeLink® will display the
status of your garage door opener with
arrow indicators (see below).
3)
4)
Garage Door Opener CLOSING
ing Orange)
Garage Door Opener CLOSED
Green)
Garage Door Opener OPENING
ing Orange)
Garage Door Opener OPENED
Green)
(Blink(Solid
(Blink(Solid
! Certification
In the event that there are still programming difficulties or questions, additional
HomeLink® information and programming
videos can be found at
www.HomeLink.com,
www.youtube.com/HomeLinkGentex, or
by calling the toll-free HomeLink-hotline
at 1-800-355-3515.
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.
