Driver Monitoring System
2 . Sit in the driver ’ s seat and face forward for a few moments .
3 . When user recognition is completed , the Hello screen appears on the center information display .
At this time , the seat position , outside mirror angle , climate control settings , combination meter display ( color LCD ) basic screen and center information display basic screen will all change based on the user information .
NOTE
. When a center information display operation switch is pressed , the user recognition screen is canceled , however user recognition continues .
. When the select lever is not in the “ P ” position , the seat position will not change even when user recognition is completed . . If user recognition fails , perform recognition again following the instructions , refer to “ When a user is not recognized ” FP436 . . User recognition is not performed while driving . . If the seat position or outside mirror angle are in motion at the time when user recognition is completed , then it is not possible to retrieve the seat position , outside mirror angle , or reverse tilt-down outside mirror angle . . If any of the following operations is performed while retrieving of the seat position or outside mirror angle , retrieving of the seat position and outside mirror angle is canceled . – The power seat adjustment switch was operated . – The outside mirror adjustment switch was operated . – The “ SET ” button was pressed . – The “ 1 ” or “ 2 ” button was pressed . – The select lever was moved to a position other than “ P ” position .
! When a user is not recognized s07bp0402
In the following case , user recognition may not be possible and “ User recognition stopped ” may be displayed .
. There is an object blocking the camera .
Remove the obstacle and follow the reference procedure to perform user recognition again . Refer to “ Driver Monitoring System ” FP233 .
1 ) Camera
NOTE
. User recognition may not be possible when there is dirt or fingerprints on the user recognition camera . To clean , either wipe using a soft cloth or else wipe gently using a moistened cloth that has been thoroughly wrung out .
