Driver Monitoring System 435 |
|||||
|
nated , the Driver Monitoring System function cannot be used . In addition , the following items cannot be selected .
. Register User . Delete User . Delete All Users . Update Seat and Mirror Position . Delete Driver Position . Automatically Retract Seat on Entry
! Driver Monitoring System operation indicator light ( green ) s07bp0301
This indicator illuminates when the Driver Monitoring System is operating .
! Driver Monitoring System OFF indicator light s07bp0302
This indicator illuminates when the user has turned off the Driver Monitoring System and the Driver Monitoring System is not operating .
! Driver Monitoring System temporary stop indicator light s07bp0303
This indicator illuminates when the Driver Monitoring System is temporarily stopped .
NOTE
The Driver Monitoring System stops temporarily in the following circumstances .
. When the temperature of the main unit of the Driver Monitoring System is
|
high or low . . When the Driver Monitoring System cannot monitor the driver ’ s eye movement . . When the Driver Monitoring System cannot monitor the driver ’ s eyebrows , eyes , nose or mouth . . When the camera and the infrared light source ( LED ) are covered and the Driver Monitoring System cannot monitor the driver correctly .
! Driver Monitoring System warning light ( yellow ) s07bp0304
This warning illuminates when there is a problem with the Driver Monitoring System . Contact a SUBARU dealer to have the system inspected .
& Using the Driver Monitoring System s07bp04
! User recognition s07bp0401
When a user is registered with the user recognition function , the Driver Monitoring System performs the following .
|
1 . When the door is opened and the push-button ignition switch is OFF , the user recognition screen appears and the Driver Monitoring system starts user recognition .
The user recognition screen may not appear when the door is opened in some cases , such as when only a short time has passed after the push-button ignition switch was turned OFF . In such cases , user recognition starts when the door is closed however the user recognition screen does not appear .
|
7
Starting and Operating
|
||
– CONTINUED – |
