360
BSD / RCTA
– When there is a difference in height between your lane and the neighboring lane
– Immediately after the BSD / RCTA is activated by touching“ Rear Vehicle Detection( BSD / RCTA)”
– Immediately after the select lever is shifted to the“ R” position
– When extremely heavy cargo is loaded in the cargo area
. During reversing, operation of the BSD / RCTA approach indicator light and the warning buzzer may be delayed or the system may fail to issue these warnings under the following conditions. – When backing out of an angled parking space – When a large-sized vehicle is parked next to your vehicle( That vehicle prevents the propagation of radar waves.) – When reversing on sloped roads – When reversing at a high speed
. The BSD / RCTA approach indicator light may illuminate when driving close to solid objects on the road or road side( such as guardrails, tunnels and sidewalls).
. When turning at an intersection in urban areas, or a multilane intersection, the BSD / RCTA approach indicator light may flash.
. If a building or a wall exists in the reversing direction, the BSD / RCTA approach indicator light may flash and the warning buzzer may sound.
. In the following cases, the system may detect a vehicle driving two lanes away from your vehicle. – When your vehicle drives on the near side of its lane from the corresponding vehicle
– When the vehicle driving two lanes away drives on the near side of its lane from your vehicle
& BSD / RCTA OFF Indicator s07bm08
! System temporary stops s07bm0801
1 BSD / RCTA temporary stop message 2 BSD / RCTA OFF indicator
This display appears when the system is used at extremely high or low temperatures or when abnormal voltage exists. Once these conditions are corrected, the system will recover from the temporary stop condition and the indicator will disappear.
