BSD / RCTA 361 |
||||||||
|
If the indicator remains displayed for a prolonged time, have the system inspected at a SUBARU dealer.
! System temporary stops due to reduced radar sensitivity s07bm0802
|
& BSD / RCTA Warning Indicator s07bm04
! System malfunction s07bm0403
|
& To Turn On / Off the BSD / RCTA s07bm09 |
||||||
|
BSD / RCTA OFF indicator
To turn the BSD / RCTA system on and off, operate the center information display. Refer to“ Car settings” FP198.
When the BSD / RCTA system is turned OFF, the BSD / RCTA OFF indicator on the combination meter display( color LCD) will illuminate.
NOTE
. If you turn off the BSD / RCTA, some EyeSight functions will also be deactivated. For details, refer to the Owner’ s Manual supplement for the EyeSight system.
. If the ignition switch is turned to the“ LOCK”/“ OFF” position, the last known status of the system is main-
|
||||||||
|
1 BSD / RCTA temporary stop message due to reduced radar sensitivity
2 BSD / RCTA OFF indicator
This display appears when the detectability of the radar sensors is reduced. Once the condition is corrected, the system will recover from the temporary stop condition and the indicator will disappear.
If the indicator remains displayed for a prolonged time, have the system inspected at a SUBARU dealer.
|
1 BSD / RCTA malfunction message 2 At first, this message will appear 3 Then this message will appear 4 BSD / RCTA warning indicator
This display appears when a malfunction occurs in the system. Contact a SUBARU dealer and have the system inspected.
|
7
Starting and Operating
|
||||||
– CONTINUED – |
