Meters and Gauges 151 |
|
& Tachometer s03ad06
The tachometer shows the engine speed in thousands of revolutions per minute.
|
& Odometer |
s03ad04 |
& Double Trip Meter |
s03ad05 |
|
CAUTION |
|||||
|
Do not operate the engine with the pointer of the tachometer in the red zone. In this range, fuel injection will be cut by the engine control module to protect the engine from overrevving. The engine will resume running normally after the engine speed is reduced below the red zone.
NOTE
The initial movement of the meter needles and gauge needles that occurs when the ignition switch is turned to the“ ON” position can be activated or deactivated.
For details, refer to“ General settings” FP196( 11.6-inch display models) or“ General settings” FP213( dual 7.0- inch display models).
|
1 TRIP RESET switch 2 Odometer
This meter displays the odometer when the ignition switch is in the“ ON” position.
The odometer shows the total distance that the vehicle has been driven.
NOTE
If you press the TRIP RESET switch when the ignition switch is in the“ LOCK”/“ OFF” or“ ACC” position, the odometer / trip meter will light up. The indicators will turn off when the TRIP RESET switch is not operated for approximately 10 seconds.
|
1 TRIP RESET switch 2 Trip meter
This meter displays the two trip meters when the ignition switch is in the“ ON” position.
The trip meter shows the distance that the vehicle has been driven since you last set it to zero.
The display can be switched as shown in the following sequence by pressing the TRIP RESET switch.
|
3
Instruments and Controls
|
||||||||||
– CONTINUED – |
|||||||||||||
