152
Meters and Gauges
To reset the trip meter, select either the A trip or B trip meter, then press and hold the TRIP RESET switch.
CAUTION
To ensure safety, do not attempt to change the function of the indicator during driving, as an accident could result.
NOTE
. If the connection between the combination meter and battery is broken for any reason such as vehicle maintenance or fuse replacement, the data recorded on the trip meter will be lost.
. If you press the TRIP RESET switch when the ignition switch is in the“ LOCK”/“ OFF” or“ ACC” position, the odometer / trip meter will light up. It is possible to switch between the A trip meter and B trip meter indications while the odometer / trip meter is lit up. In addition, it is possible to reset the trip meter by pressing and holding the TRIP RESET switch. The indicators will turn off when the TRIP RESET switch is not operated for approximately 10 seconds.
& Fuel Gauge
s03ad07
The fuel gauge shows the approximate amount of fuel remaining in the tank.
When the ignition switch is in the“ LOCK”/“ OFF” or“ ACC” position, the fuel gauge shows“ E” even if the fuel tank contains fuel.
The gauge may move slightly due to fuel level movement in the tank( e. g., during braking, turning or acceleration).
NOTE
. You will see the“” sign in the fuel gauge. This indicates that the fuel filler lid is located on the right side of the vehicle.
. If you press the TRIP RESET switch while the ignition switch is in the
“ LOCK”/“ OFF” or“ ACC” position, the fuel gauge will light up and indicate the amount of fuel remaining in the tank. The gauge will turn off when the TRIP RESET switch is not operated for approximately 10 seconds.
& Engine Coolant Temperature Gauge s03ad08
1 Normal operating range
The temperature gauge shows engine coolant temperature when the ignition switch is in the“ ON” position.
The coolant temperature will vary in accordance with the outside temperature and driving conditions.
