Windows 135 |
||||||
|
further jamming, entrapment or malfunction. – The closing window slides down slightly and stops. – The opening window stops sliding down.. The power window system may detect resistance, an impact or an abnormality in the following cases. – A substantial sized object is caught between the window and the window frame.
– A foreign object is caught between the window and the window frame.
– The vehicle drives over a deep pothole.
. The window cannot be closed for a few seconds after the window is automatically stopped by the system.
|
& Power Window Operation s02ah07
! Power window switches s02ah0701
. Driver’ s side power window switches:
|
1 For front left window * 2 For front right window * 3 For rear left window 4 For rear right window 5 Lock switch *: With one-touch auto up and down feature |
. Passenger’ s side power window switches: |
Each passenger’ s window can be controlled by the power window switch located on the door.
. Front passenger’ s window
The power window operates when the power window switch illuminates or the ignition switch is in the“ ON” position.
|
2
Keys and Doors
|
|
|
All door windows can be controlled by the power window switch cluster on the driver side door.
The power windows operate when the power window switch illuminates or the ignition switch is in the“ ON” position.
|
. Rear passenger’ s windows
The power windows operate only when the ignition switch is in the“ ON” position.
|
|||||
– CONTINUED – |
