136
Windows
! Operating the window s02ah0702
With one-touch auto up and down feature 1 Automatically close * 2 Close 3 Open 4 Automatically open *
*: To stop the window halfway, operate the switch to the opposite side.
Without one-touch auto up and down feature
1 Close 2 Open
NOTE
Avoid the following.
. Continuously operating a switch in the same direction after the window is fully closed or fully opened.
. Continuously operating three or more switches all at once in the same direction after the windows are fully closed or fully opened.
Either of the operations described above may cause the power window breaker to operate making it impossible to open or close the window. Be sure to initialize the power windows. Refer to
“ Initialization of Power Window( Windows with One-Touch Auto Up and Down Function)” FP137.
! Anti-entrapment function( windows with one-touch auto up and down function) s02ah0703
While closing the window automatically, if the window senses a substantial enough object trapped between the window and the window frame, it automatically moves down slightly and stops.
If a foreign object is caught while window is opening automatically, the window will stop.
CAUTION
. Never attempt to test the power window operation using body parts.
. If an object is caught just before the window fully closes, the system may not operate properly.
NOTE
. If a window detects an impact similar to that caused by trapping an object( for example, when the vehicle encounters a deep pothole), the antientrapment function may operate.
