266
INSTRUMENTS AND CONTROLS
To adjust the display:
After pressing the setting button, the mode will change to the up / down adjustment mode.
Up / down adjustment:
S _ 307938-W
Left button Center button Right button
Press any of the left, center or right buttons to display the main menu.
NOTE
. The main menu cannot be displayed on the display while the select lever is in a position other than the“ P” position.
. If you do not press the adjustment buttons that are at the bottom of the Smart Rearview Mirror for 5 seconds, the adjustment menu will disappear.
Brightness adjustment:
S _ 307940-W
Setting button: Press the setting button to set the angle.
Press this button to lower the angle. Press this button to raise the angle.
After pressing the setting button, the mode will change to the left / right adjustment mode.
Left / right adjustment:
S _ 307941-W
S _ 307939-W
Setting button: Press the setting button to set the brightness.
Press this button to decrease the brightness.
Press this button to increase the brightness.
Setting button: Press the setting button to set the angle.
Press this button to turn the angle left. Press this button to turn the angle right.
After pressing the setting button, the mode will change to the rotation adjustment mode.
