Maintenance tips 451 |
||||||||||
|
& When checking or servicing in the engine compartment
S11AB03
|
CAUTION
. Do not touch the engine cover while checking the components in the engine compartment . Doing so may cause your hand to slip off the cover and result in an unexpected injury .
|
. Do not touch the oil filter until the engine has cooled down completely . Doing so may result in a burn or other injury . Note that the oil filter becomes very hot when the engine is running and remains hot for some time after the engine has stopped .
& When checking or servicing in the engine compartment while the engine is running
S11AB02
WARNING
|
A running engine can be dangerous . Keep your fingers , hands , clothing , hair and tools away from the cooling fan , drive belt and any other moving engine parts . Removing rings , watches and ties is advisable . |
11-3 . Maintenance tips
S11BI
Some clips and fender linings must be removed before replacing the air cleaner elements or specific bulbs .
& Removing and reinstalling clips
S11BI01
! Removing clips
S11BI0101
There are several types of clips used for your vehicle .
! Type A clips
S11BI010101
|
Maintenance and service |
|||||
|
1 . Turn the clips counterclockwise using a flat-head screwdriver until the center portion of the clip is raised .
2 . Remove the clips with a flat-head screwdriver using leverage .
– CONTINUED –
|
