452
Maintenance tips
|
3 . Remove the entire clip by pulling it up .
! Type B clips
|
|
|
|
S11BI010102 |
! Type C clips |
S11BI010103 |
|
|
! Reinstalling clips |
S11BI0102 |
1 . Pull out the center portion of the clip using a flat-head screwdriver as shown in the illustration .
2 . Pull the protruded center portion to remove the entire body of the clip .
1 . Turn the clip counterclockwise using a Phillips screwdriver until the center portion of the clip is raised .
2 . Remove the entire clip by pulling it up .
Type A clips
Type B clips
