Depress brake pedal warning 1 Warning message
Make sure to depress the brake pedal once the vehicle has been stopped by automatic braking . Until the brake pedal is depressed , a message will be displayed on the audio / navigation monitor and the continuous beep will remain sounding .
At this time , a warning message is also displayed on the combination meter display ( color LCD ).
NOTE
The Sonar Audible Alarm function and Automatic Braking function are different operation conditions . Therefore , there are cases in which only one of these functions will activate .
|
WARNING
Depress the brake pedal immediately after the system stops the vehicle by automatic braking . Depending on the conditions of the road surface and tires , the vehicle may not remain stopped , possibly leading to an unexpected accident .
! After the vehicle is stopped by the system
S07BN0304
1 RAB OFF indicator
After the brake pedal is depressed , the RAB OFF indicator will illuminate and the system will temporarily stop operating . The RAB OFF indicator will turn off when the select lever is shifted to a position other
|
than the “ R ” position .
The system will operate again the next time the select lever is shifted to “ R ” position .
In circumstances such as the following , the Reverse Automatic Braking ( RAB ) system automatically stops operating and the RAB OFF indicator illuminates .
– There is ice , snow , mud , or other substance on the sonar sensors .
– The select lever was shifted to “ R ” when there is an obstacle located close to the rear bumper .
– A sound with a frequency close to that of the sonar used by the Reverse Automatic Braking ( RAB ) system was detected .
NOTE
. In the following cases , after the vehicle has been stopped by the Reverse Automatic Braking ( RAB ) system , brake control is released and the electronic parking brake operates . For details about releasing the parking brake , refer to “ Electronic parking brake ” FP341 . – When 2 minutes pass after the vehicle is stopped . – When any door is opened . – When the EyeSight system malfunctions .
– CONTINUED –
|
Starting and operating |
